Sharp XV-Z15000 User Manual

Appendix
-55
Control Contents Command Parameter
Return
Power ON
Standby mode
(or 30-second startup time)
Input Change Computer I R G B _ _ _ 1 OK or ERR ERR
Component I R G B _ _ _ 2 OK or ERR ERR
HDMI1 I R G B _ _ _ 3 OK or ERR ERR
HDMI2 I R G B _ _ _ 4 OK or ERR ERR
S-Video I V E D _ _ _ 1 OK or ERR ERR
Video I V E D _ _ _ 2 OK or ERR ERR
Input RGB Check I R G B ? ? ? ? 1: Computer, 2: Component,
3: HDMI1, 4: HDMI2, ERR
ERR
Input Video Check I V E D ? ? ? ? 1: S-Video, 2: Video, ERR ERR
Input Mode Check I M O D ? ? ? ? 1: RGB, 2: Video ERR
Input Check I C H K ? ? ? ? 1: Computer
2: Component
3: HDMI1
4: HDMI2
5: S-Video
6: Video
ERR
Resize Computer Normal R A S R _ _ _ 1 OK or ERR ERR
Stretch R A S R _ _ _ 2 OK or ERR ERR
Dot By Dot R A S R _ _ _ 3 OK or ERR ERR
Cinema Zoom R A S R _ _ _ 5 OK or ERR ERR
Zoom14:9 R A S R _ _ _ 7 OK or ERR ERR
Smart Zoom R A S R _ _ _ 6 OK or ERR ERR
Component Normal R B S R _ _ _ 1 OK or ERR ERR
Stretch R B S R _ _ _ 2 OK or ERR ERR
Dot By Dot R B S R _ _ _ 3 OK or ERR ERR
Cinema Zoom R B S R _ _ _ 5 OK or ERR ERR
Zoom14:9 R B S R _ _ _ 7 OK or ERR ERR
Smart Zoom R B S R _ _ _ 6 OK or ERR ERR
HDMI1 Normal R C S R _ _ _ 1 OK or ERR ERR
Stretch R C S R _ _ _ 2 OK or ERR ERR
Dot By Dot R C S R _ _ _ 3 OK or ERR ERR
Cinema Zoom R C S R _ _ _ 5 OK or ERR ERR
Zoom14:9 R C S R _ _ _ 7 OK or ERR ERR
Smart Zoom R C S R _ _ _ 6 OK or ERR ERR
HDMI2 Normal R D S R _ _ _ 1 OK or ERR ERR
Stretch R D S R _ _ _ 2 OK or ERR ERR
Dot By Dot R D S R _ _ _ 3 OK or ERR ERR
Cinema Zoom R D S R _ _ _ 5 OK or ERR ERR
Zoom14:9 R D S R _ _ _ 7 OK or ERR ERR
Smart Zoom R D S R _ _ _ 6 OK or ERR ERR
S-Video Normal R A S V _ _ _ 1 OK or ERR ERR
Stretch R A S V _ _ _ 2 OK or ERR ERR
Cinema Zoom R A S V _ _ _ 5 OK or ERR ERR
Zoom14:9 R A S V _ _ _ 7 OK or ERR ERR
Smart Zoom R A S V _ _ _ 6 OK or ERR ERR
Video Normal R B S V _ _ _ 1 OK or ERR ERR
Stretch R B S V _ _ _ 2 OK or ERR ERR
Cinema Zoom R B S V _ _ _ 5 OK or ERR ERR
Zoom14:9 R B S V _ _ _ 7 OK or ERR ERR
Smart Zoom R B S V _ _ _ 6 OK or ERR ERR
ALL Reset A L R E _ _ _ 1 OK or ERR ERR
Computer INPUT Picture Mode Standard R A P S _ _ _ 1 OK or ERR ERR
Natural R A P S _ _ _ 2 OK or ERR ERR
Dynamic R A P S _ _ _ 3 OK or ERR ERR
Movie1 R A P S _ _ _ 4 OK or ERR ERR
Movie2 R A P S _ _ _ 5 OK or ERR ERR
Game R A P S _ _ _ 6 OK or ERR ERR
Contrast -30 - +30 R A P I _ * * * OK or ERR ERR
Bright -30 - +30 R A B R _ * * * OK or ERR ERR
Color -30 - +30 R A C O _ * * * OK or ERR ERR
Tint -30 - +30 R A T I _ * * * OK or ERR ERR
Sharp -30 - +30 R A S H _ * * * OK or ERR ERR
Red -30 - +30 R A R D _ * * * OK or ERR ERR
Blue -30 - +30 R A B E _ * * * OK or ERR ERR
CLR Temp -2-+2 R A C T _ _ * * OK or ERR ERR
Picture Reset R A R E _ _ _ 1 OK or ERR ERR
Component INPUT Picture Mode Standard R B P S _ _ _ 1 OK or ERR ERR
Natural R B P S _ _ _ 2 OK or ERR ERR
Dynamic R B P S _ _ _ 3 OK or ERR ERR
Movie1 R B P S _ _ _ 4 OK or ERR ERR
Movie2 R B P S _ _ _ 5 OK or ERR ERR
Game R B P S _ _ _ 6 OK or ERR ERR
Contrast -30 - +30 R
B
P I _ * * * OK or ERR ERR
Bright -30 - +30 R
B
B R _ * * * OK or ERR ERR
Color -30 - +30 R
B
C O _ * * * OK or ERR ERR
Tint -30 - +30 R
B
T I _ * * * OK or ERR ERR
Sharp -30 - +30 R
B
S H _ * * * OK or ERR ERR
Red -30 - +30 R
B
RD_ * * *
OK or ERR ERR
Blue -30 - +30 R
B
BE_* * *
OK or ERR ERR
CLR Temp -2-+2 R
B
CT__* *
OK or ERR ERR
Picture Reset R B R E _ _ _ 1
OK or ERR ERR
XV-Z15000EUS.indb55XV-Z15000EUS.indb55 2008/12/2514:25:502008/12/2514:25:50
