Sharp XV-Z15000 User Manual

Appendix
Computer Compatibility Chart
Computer
• Multiple signal support
Horizontal Frequency: 15–110 kHz, Vertical Frequency: 43–85 Hz, Pixel Clock: 12–170 MHz
• Compatible with sync on green and composite sync signals (TTL level)
Note
• This projector may not be able to display images from notebook computers in simultaneous (CRT/LCD)
mode. Should this occur, turn off the LCD display on the notebook computer and output the display data
in “CRT only” mode. Details on how to change display modes can be found in your notebook computer’s
operation manual.
• When “Screen resolution” of the computer is different from the resolution displayed on the projected im-
age, follow the procedures shown below.
– Refer to “Resolution” on the “SIG-ADJ” menu and select the same resolution as the resolution in “Screen
resolution” of the computer.
– Depending on the computer you are using, the output signal may not be faithful to the “Screen reso-
lution” adjustment. Check the settings of the computer's signal output. If the settings cannot be
changed, it is recommended that the resolution be set to “1920 × 1080” or “1280 × 720”.
PC/MAC Mode Resolution
Horizontal frequency
[kHz]
Vertical
frequency[Hz]
Analog
Support
Digital
Support
Display
PC
VGA
640 × 400
27.0 60
✔
Upscale
31.5 70
✔
37.9 85
✔
720 × 400
27.0 60
✔
31.5 70
✔✔
37.9 85
✔
640 × 480
26.2 50
✔
31.5 60
✔✔
34.7 70
✔
37.9 72
✔✔
37.5 75
✔✔
43.3 85
✔
SVGA 800 × 600
31.3 50
✔
35.2 56
✔✔
37.9 60
✔✔
46.6 70
✔
48.1 72
✔✔
46.9 75
✔✔
53.7 85
✔
XGA 1024 × 768
40.3 50
✔
48.4 60
✔✔
56.5 70
✔✔
60.0 75
✔✔
68.7 85
✔
WXGA
1280 × 720 45.0 60
✔✔
1280 × 768 47.8 60
✔
1280 × 800 49.7 60
✔
1360 × 768 47.7 60
✔
1366 × 768 47.8 60
✔
WXGA+ 1440 × 900 55.9 60
✔
SXGA
1152 × 864
55.0 60
✔✔
66.2 70
✔
67.5 75
✔✔
1280 × 960 60.0 60
✔✔
1280 × 1024 64.0 60
✔✔
SXGA+ 1400 × 1050
64.0 60
✔✔
65.3 60
✔✔
WSXGA+
1600 × 900 55.9 60
✔✔
1680 × 1050 65.3 60
✔
1920 × 1080
*
1
66.8 60
✔
Down sampled
1920 × 1080
*
2
67.5 60
✔✔
Intelligent
Compression
MAC 13" VGA 640 × 480 34.9 67
✔
Upscale
MAC 16" SVGA 832 × 624 49.7 75
✔
MAC 19" XGA 1024 × 768 60.2 75
✔
MAC 21" SXGA 1152 × 870 68.7 75
✔
*1 When a 1920 × 1080 analog signal is input, the image is compressed before it is displayed on the screen.
*2 Full image display when “Resolution” is set to “1920 × 1080”
DTV
Signal
Horizontal
Frequency (kHz)
Vertical
Frequency (Hz)
Analog
Support
Digital
Support
Signal
Horizontal
Frequency (kHz)
Vertical
Frequency (Hz)
Analog
Support
Digital
Support
480
I
15.7 60
✔
1080
I
28.1 50
✔✔
480P 31.5 60
✔✔
1080
I
33.8 60
✔✔
540P 33.8 60
✔
1080P 27.0 24
✔
576
I
15.6 50
✔
1080P 28.1 25
✔
576P 31.3 50
✔✔
1080P 33.8 30
✔
720P 37.5 50
✔✔
1080P 56.3 50
✔✔
720P 45.0 60
✔✔
1080P 67.5 60
✔✔
-57
XV-Z15000EUS.indb57XV-Z15000EUS.indb57 2008/12/2514:25:522008/12/2514:25:52

Sharp XV-Z15000 Specifications

General

Projection distance	3.14 - 3.63 m
Projection technology	DLP
Contrast ratio (typical)	-
Screen size compatibility	300 \
Projector native resolution	1080p (1920x1080)
Aspect ratio	4:3, 16:9
RS-232 ports	1
Dimensions (WxDxH)	403 x 115 x 341 mm
Digital zoom	1.15 x
Focal length range	21 - 24.2 mm
Lamp type	SHP
Lamp power	250 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Audio (L/R) in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN	No
Supported video modes	1035i, 1080i, 1080p, 480i, 480p, 576i, 576p, 720i, 720p
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL L, SECAM
Product color	Black
Market positioning	Home cinema
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	- W
Power consumption (typical)	353 W
Noise level	23 dB

Weight and Dimensions

Weight	5800 g
