Sharp XV-Z15000 User Manual

Control Contents Command Parameter
Return
Power ON
Standby mode
(or 30-second startup time)
HDMI1 Picture Mode Standard R C P S _ _ _ 1
OK or ERR ERR
Natural R C P S _ _ _ 2
OK or ERR ERR
Dynamic R C P S _ _ _ 3
OK or ERR ERR
Movie1 R C P S _ _ _ 4
OK or ERR ERR
Movie2 R C P S _ _ _ 5
OK or ERR ERR
Game R C P S _ _ _ 6
OK or ERR ERR
Contrast -30 - +30 R C P I _ * * *
OK or ERR ERR
Bright -30 - +30 R C B R _ * * *
OK or ERR ERR
Color -30 - +30 R C C O _ * * *
OK or ERR ERR
Tint -30 - +30 R C T I _ * * *
OK or ERR ERR
Sharp -30 - +30 R C S H _ * * *
OK or ERR ERR
Red -30 - +30 R C R D _ * * *
OK or ERR ERR
Blue -30 - +30 R C B E _ * * *
OK or ERR ERR
CLR Temp -2-+2 R C C T _ _ * *
OK or ERR ERR
Picture Reset R C R E _ _ _ 1
OK or ERR ERR
HDMI2 Picture Mode Standard R D P S _ _ _ 1
OK or ERR ERR
Natural R D P S _ _ _ 2
OK or ERR ERR
Dynamic R D P S _ _ _ 3
OK or ERR ERR
Movie1 R D P S _ _ _ 4
OK or ERR ERR
Movie2 R D P S _ _ _ 5
OK or ERR ERR
Game R D P S _ _ _ 6
OK or ERR ERR
Contrast -30 - +30 R D P I _ * * *
OK or ERR ERR
Bright -30 - +30 R D B R _ * * *
OK or ERR ERR
Color -30 - +30 R D C O _ * * *
OK or ERR ERR
Tint -30 - +30 R D T I _ * * *
OK or ERR ERR
Sharp -30 - +30 R D S H _ * * *
OK or ERR ERR
Red -30 - +30 R D R D _ * * *
OK or ERR ERR
Blue -30 - +30 R D B E _ * * *
OK or ERR ERR
CLR Temp -2-+2 R D C T _ _ * *
OK or ERR ERR
Picture Reset R D R E _ _ _ 1
OK or ERR ERR
S-Video INPUT Picture Mode Standard V A P S _ _ _ 1
OK or ERR ERR
Natural V A P S _ _ _ 2
OK or ERR ERR
Dynamic V A P S _ _ _ 3
OK or ERR ERR
Movie1 V A P S _ _ _ 4
OK or ERR ERR
Movie2 V A P S _ _ _ 5
OK or ERR ERR
Game V A P S _ _ _ 6
OK or ERR ERR
Contrast -30 - +30 V A P I _ * * *
OK or ERR ERR
Bright -30 - +30 V A B R _ * * *
OK or ERR ERR
Color -30 - +30 V A C O _ * * *
OK or ERR ERR
Tint -30 - +30 V A T I _ * * *
OK or ERR ERR
Sharp -30 - +30 V A S H _ * * *
OK or ERR ERR
Red -30 - +30 V A R D _ * * *
OK or ERR ERR
Blue -30 - +30 V A B E _ * * *
OK or ERR ERR
CLR Temp -2-+2 V A C T _ _ * *
OK or ERR ERR
Picture Reset V A R E _ _ _ 1
OK or ERR ERR
Video INPUT Picture Mode Standard V B P S _ _ _ 1
OK or ERR ERR
Natural V B P S _ _ _ 2
OK or ERR ERR
Dynamic V B P S _ _ _ 3
OK or ERR ERR
Movie1 V B P S _ _ _ 4
OK or ERR ERR
Movie2 V B P S _ _ _ 5
OK or ERR ERR
Game V B P S _ _ _ 6
OK or ERR ERR
Contrast -30 - +30 V B P I _ * * *
OK or ERR ERR
Bright -30 - +30 V B B R _ * * *
OK or ERR ERR
Color -30 - +30 V B C O _ * * *
OK or ERR ERR
Tint -30 - +30 V B T I _ * * *
OK or ERR ERR
Sharp -30 - +30 V B S H _ * * *
OK or ERR ERR
Red -30 - +30 V B R D _ * * *
OK or ERR ERR
Blue -30 - +30 V B B E _ * * *
OK or ERR ERR
CLR Temp -2-+2 V B C T _ _ * *
OK or ERR ERR
Picture Reset V B R E _ _ _ 1
OK or ERR ERR
RGB Frequency Check Horizontal T F R Q _ _ _ 1 kHz (***.* or ERR) ERR
Vertical T F R Q _ _ _ 2 Hz (***.* or ERR) ERR
Lamp Timer Reset *2 L P R E 0 0 0 1 ERR OK, ERR
Note
• If an underbar (_) appears in the parameter column, enter a space. If an asterisk (*) appears, enter a value
in the range indicated in brackets under CONTROL CONTENTS.
*1
For setting the projector name, send the commands in order of PJN1, PJN2 and PJN3.
*2
The Lamp Timer Reset command can only be sent in standby mode.
RS-232C Specifi cations and Commands (Continued)
-56
XV-Z15000EUS.indb56XV-Z15000EUS.indb56 2008/12/2514:25:512008/12/2514:25:51

Sharp XV-Z15000 Specifications

General

Projection distance	3.14 - 3.63 m
Projection technology	DLP
Contrast ratio (typical)	-
Screen size compatibility	300 \
Projector native resolution	1080p (1920x1080)
Aspect ratio	4:3, 16:9
RS-232 ports	1
Dimensions (WxDxH)	403 x 115 x 341 mm
Digital zoom	1.15 x
Focal length range	21 - 24.2 mm
Lamp type	SHP
Lamp power	250 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Audio (L/R) in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN	No
Supported video modes	1035i, 1080i, 1080p, 480i, 480p, 576i, 576p, 720i, 720p
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL L, SECAM
Product color	Black
Market positioning	Home cinema
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	- W
Power consumption (typical)	353 W
Noise level	23 dB

Weight and Dimensions

Weight	5800 g
