8
⚠CAUTION! Do not use the Device if it has been damaged!
⚠CAUTION! Do not attempt to service or repair the Device yourself!
⚠CAUTION! Before starting the mounting/installation of the Device, check that the breakers
are turned off and there is no voltage on their terminals. This can be done with a mains voltage
tester or multimeter. When you are sure that there is no voltage, you can proceed to
connecting the wires.
⚠CAUTION! Do not allow children to play with the push-buttons/switches connected to the
Device. Keep the devices for remote control of Shelly Qubino (mobile phones, tablets, PCs)
away from children.
⚠RECOMMENDATION: Connect the Device using solid single-core cables or stranded cables
with ferrules. The cables should have insulation with increased heat resistance, not less than
PVC T105°C (221°F).
⚠RECOMMENDATION: For inductive appliances that cause voltage spikes during switching
on/off, such as electrical motors, fans, vacuum cleaners and similar ones, RC snubber (0.1 µF /
100 Ω / 1/2 W / 600 VAC) should be connected parallel to the appliance.
Connect the load circuit to the Device I and O terminals.
Connect the Live wire to the Device L terminal, and the Neutral wire to the N terminal as shown
on Fig. 1.
Connect a switch or a push-button to the Device SW terminal and the Live wire.
6. About Z-Wave®
The Z-Wave® protocol is an interoperable, wireless, RF-based communications technology
designed specifically for control, monitoring, and status reading applications in residential and
light commercial environments. Mature, proven, and broadly deployed, Z-Wave® is by far the
world market leader in wireless control, bringing affordable, reliable, and easy-to-use 'smart'
products to millions of people in every aspect of daily life.
Interoperability has always been at the core of the Z-Wave® protocol, alongside the features
like backward compatibility, security, and reliability. All Z-Wave® devices can be operated in any
Z-Wave® network with other Z-Wave® certified devices, regardless of brand or manufacturer.
All mains operated nodes within the network will act as repeaters regardless of vendor to
increase the reliability of the network. There are 4000+ Z-Wave certified products that are
backwards- and forwards-compatible in the Z-Wave® ecosystem and well over 100 million
devices currently in the market.
With over 20 years in the marketplace, Z-Wave® technology has best-in-class security measures
to keep your home network smarter and safer.
Source: www.Z-Wavealliance.org, http://www.Z-Wave.com
