The table below describes upper LED indicators of the Shield A-XT Releasing Fire Control Panel:
General System Status LED Color
Fire, NAC Output State
Flashing = NACs Activated
ON Continuous = NACs silenced
OFF = Panel and NACs Reset
Red
Power On Green
Delay On Yell ow
Test Mode On Yell ow
General Disablement Yell ow
Power Trouble Yell ow
NAC Trouble / Disabled Yellow
General Trouble Yell ow
System Trouble Yell ow
Buzzer Silenced Yell ow
Fire In Zone LED Color
1 Red
2 Red
3 Red
1 - Zone Trouble / Test / Disablement Yell ow
2 - Zone Trouble / Test / Disablement Yell ow
3 - Zone Trouble / Test / Disablement Yell ow
