- 20 -
5-15 SV limiter higher limit value setting screen
To 5-0 screen
Initial value: Higher limit value of measuring range
Setting range: ¦ + 1 count ~ Higher limit of
measuring range
When a wider range than the measuring range is used for target
value setting, a higher limit value is set. (It prevents erroneous
setting in a dangerous range.)
Note:In SV limiter setting, SV limiter lower limit value<SV
limiter higher limit value and the lower limit value is given
preference, that is, it is not possible to set a higher value
which is less than a lower level + 1 count.
(13) Setting External Control Input
5-16 External control input 2 (DI2) action code setting screen
To 5-0 screen
Initial value:
Setting range: (non) , (HLD) ,
(ADV)| , (FIX) ,
(SPT3)k
An action code of external control input 2 (DI2) is set. For
details of DI input, see "6-10. External Control Input." This
screen does now show j
Table of External Control Input (DI) Codes
DI code Description
Without DI
Hol
| Advance
FIX level
j Starting pattern No.2 bit
k Startin
attern No.3 bit
5-17 External control input 3 (DI3) action code setting screen
To 5-0 screen
Initial value:
Setting range:(non), (HLD),
|(ADV), (FIX) ,
(SPT2)j
An action code of external control input 3 (DI3) is set. This
screen is not displayed when the external control input 2 (DI2)
code is k
This screen does not showk
5-18 External control input 4 (DI4) action code setting screen
To 5-0 screen
Initial value:
Setting range: (non), (HLD),
(ADV)| , (FIX) ,
An action code of external control input 4 (DI4) is set. This
screen is not displayed when the external control input 2 (DI2)
code is kand when the external control input 3 (DI3)
code is j
This screen does not show jand k.
(14) Setting Events
5-19 Event 1 (EV1) type setting screen
To 5-0 screen
Initial value:
Setting range: ~
The type of event to be set as EV1 is selected from the following
table.
To 5-20 screen
Table of Event Type Codes
Code Type of event
None
Higher limit deviation
Lower limit deviation
Outside hi
her/lower limit deviations
her/lower limit deviations
her limit absolute value
Lower limit absolute value
End signal
FIX
5-20 Event 1 (EV1) hysteresis setting screen
To 5-0 screen
Initial value: 5
Measuring range: 1 ~ 999 digits
Hysteresis is set for EV1. This screen is displayed when an EV1
code is , , , , | or |.
5-21 Event 1 (EV1) standby action setting screen
To 5-0 screen
Initial value: 1
Measuring range: 1 ~ 4
EV1 standby action type code is selected from the following
table. This screen is displayed when an EV1 code is ,
, ,,| or |.
Table of Standby Action Codes
Code Description
i Without standby function
j
Standby action only when power is applied, or when
the state is switched from RST (stop) to RUN
(execution)
k
Standby action when power is applied, or when the
state is switched from RST (stop) to RUN
(execution), or when SV in execution is changed
l Control mode (without standby)
5-22 Event 2 (EV2) type setting screen
To 5-0 screen
Initial value:
Setting range: ~
The same as the 5-19 screen except EV1 changed to EV2.
5-23 Event 2 (EV2) hysteresis setting screen
To 5-0 screen
Initial value: 5
Setting range: 1 ~ 999 digits
The same as the 5-20 screen EV1 changed to EV2.
5-24 Event 2 (EV2) standby action code setting screen
To 5-0 screen
Initial value: 1
Setting range: 1 ~ 4
The same as the 5-21 screen except EV1 changed to EV2.
5-25 Event 3 (EV3) type setting screen
To 5-0 screen
Initial value: RUN
Setting range: ~
The same as the 5-19 screen except EV1 changed to EV3.
To 5-26 screen
¦
phrh
j
k
l
~i¦
~i¦
i
~j¦
~j¦
m
~j¦
i
~i¦
~k¦
To Next Page
