- 26 -
Jumpers
JBAT1 : Clear CMOS setting
JP1A1/JP1B1 : CPU Clock setting
JP1 : DRAM Voltage setting
J2A/B/C/D : DDR/SDR DRAM Type Selector
J3A/B/C/D
JP2 : Keyboard Power On setting
Back Panel Connectors
KB : PS/2 keyboard port
MS : PS/2 mouse port
LAN : RJ45 LAN Port (MV43N only)
USB : 2 USB (Universal Serial Bus) ports
PRINTER : Parallel port (DB25 female)
COM1 : Serial port 1
VGA : VGA Port
LINE-OUT : Line-Out Port
LINE-IN : Line-In Port
MIC-IN : Mic-In Port
MIDI/GAME : MIDI/GAME Port
Front Panel Connectors
HD_LED : IDE drive active LED
SP_ LED : Green LED
RST : Hardware reset switch
PW_BN : ATX power on/off momentary type switch
SPK1 : Speaker Connector
J12 : Sleep Switch
J16 : LAN LED Indicator
USB1/USB2 : Extcnded USB Headers( USB Port3/4 & 5/6)
A1
B1
B2
B3
B4
B1
B5
B6
B7
B8
C1
C2
C3
C4
C5
C6
C7
A2
A3
A3
A4
B9
B10
C8
