Shuttle MV43 - Page 28

- 27 -
Internal Peripherals Connectors
FDC : Floppy disk drive interface
IDE1 : IDE primary interface (Dual-channel)
IDE2 : IDE secondary interface (Dual-channel)
Other Connectors
CN5 : ATX power connector
CPU FAN : CPU fan connector
SYSTEM FAN : System fan connector
WOL1 : Wake-On-LAN connector
WOM1 : Wake-On-Modem connector
SIR1 : IR header
CD1/CD2 : Onboard Audio Connectors
PANEL1 : Front-Panel Audio Line_Out/ Mic_In connector
E1
E3
E4
E5
E2
E2
D1
D1
D1
E6
E7
