Rate Tolerance
Factory default setting is 15 and
should only be altered during
sea trials
• With Main Screen displayed
(Figure 14)
• Hold MODE button, Settings Page
1 will appear (Figure 15)
• Press ► to scroll down to RATE
TOLERANCE
• Press AUTO to edit RATE
TOLERANCE
• Press ► to increase setting (more
tolerance to the rate of turn error)
• Press ◄ to decrease setting (less
tolerance to the rate of turn error)
• Press MODE to return to Settings
Page 1
• Press MODE to return to Main
Screen
Rate of Turn
(Max Rudder Angle)
Factory default setting is 500°M and
should only be altered during
sea trials
• With Main Screen displayed
(Figure 14)
• Hold MODE button, Settings Page 1
will appear (Figure 15)
• Press ► to scroll down to RATE
OF TURN
• Press AUTO to edit RATE OF
TURN
• Press ► to increase setting
(more attack angle)
• Press ◄ to decrease setting
(less attack angle)
• Press MODE to return to Settings
Page 1
• Press MODE to return to Main
Screen
Period
Factory default setting is 4 and should
only be altered during sea trials
• With Main Screen displayed
(Figure 14)
• Hold MODE button, Settings Page
1 will appear (Figure 15)
• Press ► to scroll down to PERIOD
• Press AUTO to edit PERIOD
• Press ► to increase setting (longer
delay between rudder pulses)
• Press ◄ to decrease setting
(shorter delay between rudder
pulses)
• Press MODE to return to Settings
Page 1
• Press MODE to return to Main
Screen
Dead Band
Factory default setting is 1.0°
and should only be altered during
sea trials
• With Main Screen displayed
(Figure 14)
• Hold MODE button, Settings Page
1 will appear (Figure 15)
• Press ► to scroll down to DEAD
BAND
• Press AUTO to edit DEAD BAND
• Press ► to increase setting
(more allowance for error)
• Press ◄ to decrease setting
(less allowance for error)
SI-TEX SP-110C 19 of 35
Note: This limits the max turn
speed of the vessel. Reduce this
to reduce the angle of attack for
getting to target heading.
Note: Increasing the Rate
Tolerance too high can cause
vessel wandering
