Network (CLX 200 Standard/CLX 200 Ack-Nak)
“CLX 200 Standard” enables the CLV to communicate with the CLX 200 without positive confirmation or repetition request. This
must be selected for data exchange with the CLX 200.
“CLX 200 Ack-Nak” enables the CLV to communicate with the CLX 200 in accordance with Ack-Nak protocol.
Please refer to the DNC 200 user manual for more information on our network.
3964 ...... 3964 R-Mode (BCC) (yes/no)/Priority High (yes/no)/RK 512 (yes/no)
This is a customized host interface that will not be used by many users. Contact SICK Optic technical support for detailed infor-
mation.
Note: If the CLV is in the network mode, the CLV utility software cannot comunicate. Use the icon to establish communi-
cation and remember to reset this parameter during the last download.
45
SICK Optic-Electronic
Bar Code Scanners
3
Software Configurations
Figure 3-27 Network Configuration
