SICK CLV 410 - CLV 410412 Side Scanning End Scanning Dimensions

Specifications
68
SICK Optic-Electronic
Bar Code Scanners
6
105¡
4 mm
(.15 in)
M4, 6 mm (.23 in) deep
AVOID
EXPOSURE
LASER
RADIATION
EMITTED FROM
THIS APERTURE
35.2 mm
(1.38 in)
32.8 mm
(1.30 in)
59 mm
(2.32 in)
13.2 mm
(.52 in)
14.4 mm
(.57 in)
6¡
15.3 mm
(.60 in)
0.2 mm
(.08 in)
60¡
39.3 mm
(1.56 in)
72 mm
(2.83 in)
35.9 mm
(1.42 in)
45.8 mm
(1.82 in)
50¡
39.3 mm
(1.56 in)
Line/raster scanner with end scanning housing
Right angle line/raster scanner with side scanning housing:
35.2 mm
(1.39 in)
27.1 mm
(1.08 in)
62.7 mm
(2.47 in)
62.7 mm
(2.46 in)
10 mm
(.39 in)
32.8 mm
(1.30 in)
14.4 mm
(.57 in)
10 mm
(.40 in)
4 mm
(.16 in)
M4, 6 mm (.23 in) deep
CLV 410 / 412 / 414
