SICK CLV 410 - Specifications; Scanning and Electrical Specifications

Scanning Characteristics
Scanning Method 8-sided polygon mirror wheel
Aperture Angle 60° (50° with right angle version)
Scanning Frequency 200 to 800 Hz
Light Source visible laser diode (670 nm)
Power Rating Average power at reading window: maximum 1 mW
Laser Class IEC 825 Laser Class 2 (CDRH Laser Class II)
Reading Distance 40 m to 400 m (1.5 in to 16 in)
Resolution CLV 410 - 0.2 mm to 1.0 mm (.008 in to .040 in) CLV 412 - 0.1 mm to .2mm (.004 in to .008 in)
Bar Code Types
Bar Code Symbology Code 39, Interleaved 2/5, Industrial 2/5
Codabar, Code 93, EAN/EAN 128, UPC, Code 128, Pharmacode
Readability 10 bar codes per reading
Autodiscrimination 3 different symbologies per scan or reading gate
Multiple Reads 1 to 99
Communication
Host Interface RS 232 and RS 422/485
Baud Rate 300 to 57,600
Data Format Data bits, stop bits, parity
Data String Format ASCII (header, separator, terminator)
Network Configuration Pass-through; master/slave; RS 485 network
Trigger Methods
I/O Interface Hardware trigger
Host Interface Software trigger
Free-Running Continuous scanning
Reflector Polling Automatic Trigger
Electrical Specifications
Supply Voltage 5-30 V DC (± 5% at 5 V DC, ± 20% at 24 V DC)
Current Consumption 100 mA
LED Indicators Device ready, result, laser on, data
Switching Inputs 2 x PNP, opto-decoupled, maximum 30 V DC. Internal delay 30 ms
Switching Outputs 3 X PNP, maximum 600 mA / 24 V DC: device ready, read result
Enclosure Rating IP 54 (NEMA 12), FCC Class A Part 15 compliance/class 3 (VDE 0106) (IP 65 optimal)
Ambient Operating Temperature 0 to 40°C (32 to 104°F)
Storage Temperature -20 to 70°C (-4 to 158°F)
Vibration Test To IEC 68-2-6 test FC
Shock Test To IEC 68-2-27 test EA
EMV Test To IEC 801
Max. Rel. Humidity 90% non-condensing
Connecting Cable 15-pin male Sub-D high density, .9 m (3 ft) cable length
Dimensions (L x W x H) 59 mm x 62.7 mm x 35.2 mm (2.32 in x 2.47 in x 1.39 in)
Weight Approximately 250 g (8.75 oz)
