SICK Inspector83x - Performance; Interfaces

12.3 Performance
Inspector83x
Sensor resolution V2D8305x–xxxxxxxxxx: 5megapixel (2464px x 2048px)
Scan/frame
rate
1)
30 Hz, at 5 megapixels resolution
1)
Maximum, lower at long exposure times. Image capture time only, does not include additional required
processing time.
12.4 Interfaces
Inspector83x
Ethernet Protocol: TCP/IP
Function:
•
FTP (image transfer)
•
Data interface (result output)
•
Command channel
•
Trigger interface
•
Device configuration (web user-interface) Kolla hur detta är skrivet på
andra ställen
Data transmission rate: 10/100/1000Mbit/s
EtherNet/IP™
Dual Port
Protocol: EtherNet/IP™
Function:
•
Data interface (result output)
•
Trigger interface
•
Command channel
Data transmission rate: 10/100Mbit/s
PROFINET Dual
Port
Protocol: PROFINET
Function:
•
Data interface (result output)
•
Trigger interface
•
Command channel
Data transmission rate: 10/100Mbit/s
Optical displays 8 status LEDs
Operator interfa‐
ces
Web server
Configuration
software
Web GUI (SensorApp configuration), SICK AppManager (IP determination
and configuration, SensorApp installation), SICK AppStudio (programming)
Data storage and
retrieval
Image and data storage via external FTP
Inputs/outputs 2 x insulated inputs, physical, switching
6 x configurable inputs/outputs, physical, switching (4 on Power-I/O connec‐
tor, 2 on External illumination connector)
Maximum
encoder fre‐
quency
50kHz
External illumina‐
tion
Powered by an external voltage supply, or by V
out
(max 1A) on external
illumination 4-pol connector.
Triggered via digital output on 17-pol connector, or on external illumination
4-pol connector.
