NOTE
Make sure that the lens is sufficiently secured. Use a medium strength threadlocking
adhesive, if there are high loads due to shocks and vibrations.
NOTE
Possible impairment of image quality
Contamination (e.g. dust, fingerprints) on the image sensor can impair the image
quality and decoding performance of the product.
►
Ensure a dust-free and dry environment when mounting components.
►
Do not touch the image sensor in the light inlet opening of the product with your
fingers.
►
Do not touch the glass lenses at either end of the lens unit with your fingers.
Prerequisites
•
There is a risk of burns at ambient temperatures above 30°C. If the ambient tem‐
perature is above 30°C, disassemble the optics cover and make fine adjustments
to the mounted lens within 20minutes after switching on the cooled device.
•
Lens and illumination unit are compatible with the product. You can find compati‐
ble accessories on the product page on the Internet.
•
SW2-hex key
•
SW5 socket wrench, recommendation: as a torque wrench for 65Ncm
Approach
1. Switch off the supply voltage to the device.
2. Place the camera housing on a nonslip base.
3. Remove the protection cap from the camera housing that covers the electrical
connection for the illumination unit and the light inlet.
4. Insert the connection board for the illumination into the electrical connection slot
in the device body. Do not touch the contacts to prevent ESD issues.
5. Screw the lens unit into the C-mount thread until it engages.
6. Take 2 pairs of screws and screw them into the tapped blind holes to mount each
spacer on the camera housing.
7. Make sure that the illumination connection board is pushed into the electrical
connection slot on the illumination.
8. Use the 4 screws to fasten the illumination unit to the two spacers.
9. In systems subjected to heavy vibrations, secure the screws used to mount the
lens and illumination unit using threadlocking adhesive.
10. Manually preset the sharpness and aperture of the lens unit.
11. Check the adjustment using the WebGUI.
12. If the required adjustments to the lens are not carried out immediately, mount the
optics protection hood for the lens.
6.3 Assembling the product
Approach
1. Mount the product on suitably prepared mounting equipment using M5 screws
and by means of the threaded mounting holes or sliding nuts. Mounting equip‐
ment is available as an accessory.
