Display LED Color Status
Tch
(Teach-in)
O
Blue Teach-in selected (default: Match code)
Ö
Blue Teach-in started
O
Green Teach-in successful
O
Red Teach-in unsuccessful (match code default setting: Unable
to teach in any code)
A-S
(Auto-
Setup)
O
Blue Set-up selected
Ö
Blue Set-up started
O
Green Set-up successfully quit
O
Yellow Set-up partially successful (in at least one of the 3 para‐
meter modules)
O
Red Setup unsuccessful
Usr
(User)
O
Green Function can be defined by user
O
Yellow Function can be defined by user
O
Blue Function can be defined by user
O
Red Function can be defined by user
O = illuminated; Ö = flashing
Functions
Table 7: Function overview
Function Description
Test (read diagnostics) Percentage analysis: The device records a series of images and uses
the current reading performance settings to decode them. With the
0 ... 100% bar graph, the device shows the read rate of the last 10%
(90% to 100%).
The bar graph display is activated in standard read mode.
Teach When you teach in a match code, the device reads the code that is
presented and saves the code permanently as a target code for future
code comparisons during read mode. For Pharmacodes, the Code type &
code length function must first be defined in SOPAS ET.
Auto-Setup The device adjusts itself automatically to suit the lighting conditions,
working distance
1)
, and quality of the code presented. The device
permanently stores the acquired values as per the default setting.
1)
Only applies for Dynamic Focus.
3.3.3 Memory card
The device has a card slot integrated in the housing. The card slot accommodates a
memory card in microSD format.
NOTE
The microSD memory card is optional and not included in the scope of delivery of the
device. The device supports memory cards up to max. 16 GB.
Only use types (industrial standard) approved by SICK to ensure reliable function of the
memory card. You can find these as accessories online at:
•
www.sick.com/Lector64x
•
www.sick.com/Lector65x
The memory card has no write protection that can be activated.
