Description of the device window
The device window features various views supporting a selection of functions:
(Start): Start device configuration with display of information about the device
(left-hand side) and display of the current scan (right-hand side).
The scan view can be customized with the assistance of various tools (to the left of
the scan view), for example:
: Resets scan display to default view.
/ : Displays measured values as points or lines.
: Freely rotates scan display.
Default settings: Scan display (left-hand side), entry of the basic device parameters
(right-hand side):
Application: Scan display (left-hand side) and entry of more parameters (right-hand
side):
7
OPERATION
36
O P E R A T I N G I N S T R U C T I O N S | LMS4400/LMS4500 8023202/16S6/2020-01-24 | SICK
Subject to change without notice
