Dimensional drawing
77.8
(3.06)
26.6
(1.05)
103.4
(4.07)
52.2
(2.06)
1
0
45.7
(1.80)
70°
105 (4.13)
57.4 (2.26)
370 (14.57)
192 (7.56)
98 (3.86)
5.9 (0.23)
20
(0.79)
5
93.9 (3.70)
1.0
(0.04)
6
7
129.9 (5.11)
12.8
(0.50)
111 (4.37)
CAUTION
LASER RADIATION IS
AVOID EXPOSURE –
EMITTED FROM THIS APERTURE
106.6 (4.20)
4.2
(0.17)
120.9 (4.76) 79.1 (3.11)
396.1 (15.59)
388.8 (15.31)
0
91.2 (3.59)
28 (1.10)
35.7 (1.41)
2
3
4
35.7
(1.41)
47.4
(1.87)
91.2 (3.59)
45.2
(1.78)
8
Figure 20: Dimensional drawing of the LMS4x2xx with laser protection hood; dimensions in mm
(inch), decimal separator: period
1
Interfaces, types and number can vary
2
Transmission range
3
Receiving range
4
Aperture angle
5
Laser protection hood
6
Alignment hole for the locating pin of the alignment bracket
7
Zero point of the distance measurement (marking on the top and the bottom side of the
device)
8
Threaded mounting hole M6 x 6, max. screw length 7.5 mm
10.5 Ambient data
Object remission LMS4x2x: 2% … 200%
Electromagnetic compati‐
bility (EMC)
EN 61000-6-3:2007+A1:2011 /
IEC 61000-6-3:2006+AMD 1:2010
TECHNICAL DATA 10
8023202/16S6/2020-01-24 | SICK O P E R A T I N G I N S T R U C T I O N S | LMS4400/LMS4500
49
Subject to change without notice
