Ethernet – data transmis‐
sion rate
100/1,000 Mbit/s, full duplex, half duplex
Digital inputs 0
Encoder inputs 2 (phase A, phase B), max. 50 kHz
Digital outputs 0
Synchronization input/
output
1 (master/slave)
max. 100 mA at the output (parameterization as master)
max. 2 V voltage drop in relation to V
s
Optical indicators 4 LEDs
Configuration software SOPAS ET, version 2018.2 or higher
CAN – data transmission
rate
20 kbit/s … 1 Mbit/s
CAN – function SICK CAN sensor network CSN (slave)
Telegram language CoLa ASCII
CoLa binary
10.4 Mechanics/electronics
Electrical connection 1 x M12, 5-pin male connector (CAN IN)
1 x M12, 8-pin female connector (Ethernet)
1 x M12, 5-pin female connector (CAN OUT)
1 x M12, 5-pin female connector (encoder + sync)
Supply voltage (V
s
) 24 V DC ± 25%
Permissible residual ripple ≤ 5 %
Voltage output (V
out
) 24 V DC ± 25% (identical to V
s
)
Max. output current ≤ 1,5 A and depending on external power sup‐
ply
Power consumption ≤ 16 W (typical, at 24 V DC)
≤ 29 W (start-up current)
17 W (max. continuous, all outputs loaded, devices not cascaded)
Output current ≤ 100 mA per output
Housing Aluminum die cast
Front screen material Float glass
Housing color Light blue (RAL 5012)
Enclosure rating IP65 (IEC 60529:1989+AMD1:1999+AMD2:2013)
Protection class III (IEC 61140:2016-01)
Electrical safety IEC 61010-1:2011
Weight LMS4x2x: 3.7 kg
Dimensions (L x W x H) LMS4x2x: 397 mm x 370 mm x 107 mm
10 TECHNICAL DATA
48
O P E R A T I N G I N S T R U C T I O N S | LMS4400/LMS4500 8023202/16S6/2020-01-24 | SICK
Subject to change without notice
