SICK microScan3 Technical Information

6 Technical data
6.1 Data sheet
Table 3: Miscellaneous data
Devices with a max. protective
f
ield range of 4.0 m
Devices with a max. protective
field range of 5.5 m
Devices with a max. protective
field range of 9.0 m
Scanning angle 275° (–47.5° to 227.5°)
Distance measurement range
1)
At 10% remission ≤ 12 m ≤ 22 m
At 100% remission ≤ 40 m ≤ 64 m
Scanning frequency
Scan cycle time 30 ms 33 Hz –
Scan cycle time 40 ms 25 Hz 25 Hz
50 ms scan cycle time – 20 Hz
Angular resolution (physical)
2)
Scan cycle time 30 ms < 0.01° –
Scan cycle time 40 ms < 0.01° < 0.01°
50 ms scan cycle time – < 0.01°
Angular resolution (safeHDDM®)
2)
Scan cycle time 30 ms 0.51° (537 safeHDDM® mea‐
sur
ed value)
–
Scan cycle time 40 ms 0.39° (715 safeHDDM® mea‐
sur
ed value)
0.125° (2.200 safeHDDM®
measured value)
50 ms scan cycle time – 0.1° (2.750 safeHDDM®
measured value)
Light spot size (W x H)
At 5.0 m distance 1.7 mm × 18 mm 4 mm × 20 mm
At 10.0 m distance 15 mm × 31 mm 2 mm × 35 mm
At 20.0 m distance 52 mm × 63 mm 12 mm × 69 mm
At 30.0 m distance 78 mm × 91 mm 23 mm × 104 mm
At 40.0 m distance 117 mm × 127 mm 34 mm × 139 mm
At 50.0 m distance – 43 mm × 174 mm
At 60.0 m distance – 59 mm × 222 mm
Measurement uncertainty
3)
Systematic errors ± 10 mm
Total measurement error (statistical and systematic)
At 1 σ ± 13 mm ± 18 mm
At 2 σ ± 16 mm ± 26 mm
At 3 σ ± 19 mm ± 34 mm
At 4 σ ± 22 mm ± 42 mm
At 5 σ ± 25 mm ± 50 mm
1)
Warm-up time ≥ 30 min. Light spot fully on the target object.
2)
safeHDDM® filters the physical measured values and provides very precise and reproducible measured
v
alues. Only safeHDDM® measured values are available via data output.
3)
Typical values at 20 °C and 1.8% remission, distance = protective field range.
6 T
ECHNICAL DATA
18
T E C H N I C A L I N F O R M A T I O N | microScan3, outdoorScan3 8022708/2019-04-15 | SICK
Subject to change without notice
