Table 64: NavData_tLatestTelegram: Sensor response (example)
CoLa2 telegram (HEX) ISO 8859-15
02 02 02 02 00 00 02 f0 00 00 73 61 cf 5f 00 03
52 41 b3 00 52 02 00 00 6d b5 0a 01 8c 8f 0a 01
00 00 00 00 61 02 00 00 7c 02 00 00 00 00 00 00
d4 58 00 00 4c 00 10 00 60 00 18 00 7c 00 c4 00
44 01 90 00 d8 01 08 01 00 00 00 00 00 00 00 00
00 00 00 00 00 00 00 00 00 00 00 00 01 00 00 00
01 55 00 00 ff 00 00 00 00 00 01 00 00 00 00 00
01 00 00 00 01 00 30 00 1e 00 00 00 c0 2d 5c fd
f8 d5 20 00 2b 00 00 00 00 00 00 00 01 00 00 00
30 00 00 00 80 05 1a 01 83 05 1a 01 83 05 1a 01
86 05 1a 01 85 05 1a 01 85 05 1a 01 88 05 1a 01
88 05 1a 01 8c 05 1a 01 8d 05 1a 01 90 05 1a 01
[…]
..........sa._..
RA..R...m.......
....a...|.......
.X..L...`...|...
D...............
................
.U..............
......0......-\.
.. .+...........
0...............
................
................
[…]
7.3.2 Methods
7.3.2.1 Identifying the device
Overview
Name FindMe
Index 14
Data type (input) UInt
Data type (output) –
User group Run
Description
T
he method allows the display of the device to flash for a defined period of time. Flash‐
ing can help the user to identify the device.
Input parameter
Duration of the flashing in seconds, coded as UInt.
Output values
None.
Communication example
Table 65: FindMe: Method invocation
CoLa2 telegram (HEX) ISO 8859-15
02 02 02 02 00 00 00 0e 00 00 b0 36 2c 2d 00 02
4d 49 0e 00 05 00
...........6,-..
MI....
Table 66: FindMe: Sensor response (example)
CoLa2 telegram (HEX) ISO 8859-15
02 02 02 02 00 00 00 0c 00 00 b0 36 2c 2d 00 02
41 49 0e 00
...........6,-..
AI..
ANNEX 7
8022708/2019-04-15 | SICK T E C H N I C A L I N F O R M A T I O N | microScan3, outdoorScan3
55
Subject to change without notice
