SICK microScan3

Structure Data type Length in bytes Offset in bytes Description
Messages Host SCont 1
Offset (Block
application data)
+ 197
Bit 0: Contamination warning
Bit 1: C
ontamination error
Bit 2: Manipulation
Bit 3: Dazzle
Bit 4: Reference contour monitoring
Bit 5: Critical error
Bit 6, 7: Reserved
Reserved 1
Offset (Block
application data)
+ 198
Reserved 1
Offset (Block
application data)
+ 199
Reserved 1
Offset (Block
application data)
+ 200
Reserved 1
Offset (Block
application data)
+ 201
Reserved 2
Offset (Block
application data)
+ 202
Reserved 6
Offset (Block
application data)
+ 204
Reserved 2
Offset (Block
application data)
+ 210
Reserved 44
Offset (Block
application data)
+ 212
Reserved 7
Offset (Block
application data)
+ 256
ANNEX 7
