Figure 4: Zero point / physical zero position
1
Zero point / physical zero position
2
Positive positions
3
Negative positions
4
Sensor detection range: 2,500 digits ... -2,500 digits
5
Piston position
6
Sensor position output
3.3.4 Switching behavior after Manual Teach of up to 3 switching points
Switching behavior after Manual Teach is as follows per switching point during operation:
