Figure 8: Movement in the direction of the cable connection
3.3.6 Switching behavior after Dynamic Teach of 3 switching points
If the sensor, during Dynamic Teach, detects teach 3 x piston status v = 0, 3 switching
points are set.
Example: Arrangement of switching points for dynamic teach-in of 3 switching points
on a pneumatic internal or external gripper
The switching points are assigned as follows:
Qint1 = idle
Qint2 = object
Qint3 = noobject
The assignment of the idle and no object states to gripper open or gripper closed
depends on the gripper type:
1. External gripper:
Table 3: External gripper
Gripper open
without object
idle
Gripper closed
with object
object
Gripper open
without object
idle
Gripper closed
without object
noobject
Gripper open
without object
idle
v = 0
v = 0
1. Stop
v = 0
1. Stop
2. Stop
v = 0
1. Stop
2. Stop
3. Stop
v = 0
Qint 2
Qint 1
Qint 3
PRODUCT DESCRIPTION 3
