144
MSL coded version
8 007 898/O369/05-04-04 Operating instruction • MSL cod. © SICK AG • Industrial Safety Systems • Germany • All rights reserved
Type Designation Part number
Cable receptacle
for receiver unit, straight, 6-pin + PE 6 006 612
for receiver unit, angled, 6-pin + PE 6 006 613
for receiver unit, 11-pin + PE, straight, with crimp contacts 6 020 757
for receiver unit, 11-pin + PE, angled, with crimp contacts 6 020 758
Auxiliary muting module
MSM 1 013 769
Indicator lamp, incl. 2 m cable, plug, incl. mounting kit with mounting
brackets for attachment to MSM 2 017 768
Indicator lamp, incl. 10 m cable, with plugs for MSM 2 018 504
Indicator lamp, LED design, incl. mounting kit and plug for MSM
with 2 m cable 2 019 909
with 10 m cable 2 019 910
Sensor cable with plug for MSM
2 m long 6 010 974
5 m long 6 010 976
10 m long 6 008 652
Sensor cable complete with plug for MSM and cable receptacle for WT 24
2 m long 6 008 649
5 m long 6 008 650
Sensor cable complete with plug for MSM and cable receptacle
for WL 12, WL 14, WL 18, WL 23 and WL 27
2 m long 6 021 092
5 m long 6 021 093
Angled plug for muting sensor without cable 6 008 651
Replacement lamp 6 008 654
Replacement housing 6 008 645
Mounting columns
Mirror column 400, fully mounted 1 015 040
Equipment column 400, with mounting kit 2 018 153
Mirror column 500, fully mounted 1 015 041
Equipment column 500, with mounting kit 2 018 154
Mirror insert complete 2 018 537
Mirror insert 45° 2 018 547
Adapter plate for floor fixing 4 031 053
Corner mirrors
PSK 45, not suitable for column mounting 5 306 053
PSZ 01-1501 in MSLZ housing, 500 mm beam gap 1 015 693
PSZ 01-1401 in MSLZ housing, 400 mm beam gap 1 015 897
PSZ 02-1011 S 01 for MSLZ 02-203 xxx 1 019 225
**) Four sliding blocks supplied with each sender and each receiver
**) Specially recommended when using the MSM
The basic specification is highlighted in gray. The connector system must be ordered separately.
