MSL coded version
8 007 898/O369/05-04-04 Operating instruction • MSL cod. © SICK AG • Safety Systems • Germany • All rights reserved
Hirschmann (6 + PE)
Hirschmann (6 + PE)
2
1
3
4
5
6
1
1+ 24 V
20 V
3 Test 
4 Test 
5 n. c.
6 n. c.
PE
1+ 24 V
20 V
3 OSSD 1
4 OSSD 2
5 RES
6 EDM
PE
Hirschmann (11 + PE)
1+ 24 V
20 V
3 OSSD 1
4 OSSD 2
5 RES
6 EDM
7 OWS
PE
8
Part numbers
Quick-disconnect plug 7 021 353
Cable entry receptacle
straight 6 006 612
angled 6 006 613
Part numbers
Quick-disconnect plug 2 018 539
Cable entry receptacle
straight 6 006 612
angled 6 006 613
Part numbers
Quick-disconnect plug 2 018 584
Cable entry receptacle
straigt 6 020 757
angled 6 020 758
1
3
2
4
5
6
7
1
2
3
4
5
6
7
2
1
3
4
5
6
1
241967_MSLcod_App.p65 10.12.04, 13:48298
