表格 92: 没有 IO-Link 的 RAY10
推挽式 -AB1xxL -BA1xxL -AB3xxL -AB5xxL -BA3xxL -BA5xxL -AB4xxL -BA4xxL
PNP
-PF1xxx -FP1xxx -PF3xxx -PF5xxx -FP3xxx -FP5xxx -PF4xxx -FP4xxx
NPN
-NE1xxx -EN1xxx -NE3xxx -NE5xxx -EN3xxx -EN5xxx -NE4xxx -EN4xxx
1
BN + (L+) + (L+) + (L+) + (L+) + (L+) + (L+)
2
WH
Q
Q
Q
Q
Q
Q
3
BU - (M) - (M) - (M) - (M) - (M) - (M)
4
BK Q
Q
Q
Q
Q
Q
0.14 mm
2
AWG26
2
1
4
3
1
2
4 3
表格 93: 没有 IO-Link 的 RAY10，报警
RAY10 -AT1xxL -BT1xxL -AT3xxL -AT5xxL
-BT3xxL -BT5xxL -AT4xxL -BT4xxL
1
BN + (L+) + (L+) + (L+) + (L+) + (L+) + (L+)
2
WH Alarm Alarm Alarm Alarm Alarm Alarm
3
BU - (M) - (M) - (M) - (M) - (M) - (M)
4
BK Q
Q
Q
Q
Q
Q
0.14 mm
2
AWG26
2
1
4
3
1
2
4 3
表格 94: 没有 IO-Link 的 RAY10
RAY10
-xxAxxx -xxBxxx -xxCZxx
-xxDxxx
-xxExxx
1
- + (L+) + (L+) + (L+) Q
2
+ (L+)
Q
Q Q
Q
3
Q - (M) - (M) - (M) + (L+)
4
Q
Q -
Q
- (M)
5
- (M) - - - -
2 5
1 2
3 4
3
2 1
34 2 1
34
12
电气安装 6
8022198.1BXN / 2021-05-26 | SICK 操 作 指 南 | RAY10
155
如有更改，恕不另行通知
zh
