12 Technical data
12.1 Electrical and mechanical data
RAY10
Sensing range max. (with reflector P250F) 0 ... 1.5 m
1)
Light band dimensions / distance approx. 37 * 12 mm / 1 m
Minimum detectable object (MDO) ≥ 5 mm
Suppression of objects < 1 mm
Minimum distance between sensor and reflector 300 mm
Supply voltage U
B
DC 10 ... 30 V
Current consumption ≤ 30 mA
2)
, < 50 mA
3)
Output current I
max.
≤ 100 mA
Communication mode COM2
IO-Link 1.1
Max. response time ≤ 0.5 ms
4)
Switching frequency 1000 Hz
5)
Enclosure rating IP67
Protection class III
Circuit protection A, B, C, D
6)
Ambient operating temperature -40 °C ... + 60 °C
1)
We recommend using compound triangular reflectors or reflective tape to ensure reliable operation. Suitable reflectors and foils can be
found in the SICK accessories range. Use of reflectors with large-scale triple structures can negatively influence functionality.
2)
16 VDC to 30 VDC, without load
3)
10 VDC to 16 VDC, without load
4)
Signal transit time with resistive load in switching mode. Deviating values possible in COM2 mode.
5)
With a light/dark ratio of 1:1 in switching mode. Deviating values possible in IO-Link mode.
6)
A = U
B
-connections reverse polarity protected
B = inputs and output reverse-polarity protected
C = Interference suppression
D = outputs overcurrent and short-circuit protected
TECHNICAL DATA 12
8022198.1BXN / 2021-05-26 | SICK O P E R A T I N G I N S T R U C T I O N S | RAY10
33
Subject to change without notice
en
