SICK MultiTask RAY10 User Manual

NOTE
The adjustment of the height (1) should be separated from the adjustment of the angle
(2).
Table 18: Adjustment
Figure 16: (1)
Figure 17: (2)
COMMISSIONING 7
8022198.1BXN / 2021-05-26 | SICK O P E R A T I N G I N S T R U C T I O N S | RAY10
27
Subject to change without notice
en
