Figure 7: Mounting angle to use, depending on the application
1
Typical angle 10° ... 20°
The typical value is between 10° and 20°.
Depending on the application, an angle of between 0° (bright field light) and 45° (dark
field light) may be advisable.
5
MOUNTING
32
O P E R A T I N G I N S T R U C T I O N S | Lector63x Flex C-mount and S-mount 8018071/16XD/2020-05-06 | SICK
Subject to change without notice
