SICK V2D632R-MXSXB0 - Performance and Interfaces

11.3 Performance
Type Lector63x Flex (V2D63xx-Mxxxxx)
Readable code struc‐
tures
1D, Stacked, 2D, DPM, OCR/OCV
1D code types (bar
code)
GS1-128 / EAN 128, UPC/GTIN/EAN, 2/5 Interleaved, Pharmacode, GS1 DataBar, Code 39, Code
128, Codabar, Code 32, Code 93
Postal codes Postnet, Planet, USPS 4SCB, Australia Post, Dutch KIX Post, Royal Mail, Swedish Post
2D code types Data Matrix ECC200, GS1 Data Matrix, MaxiCode, QR-Code
Stacked code types PDF417
Code qualification Based on ISO/IEC 16022, ISO/IEC 15415, ISO/IEC 18004
OCR/OCV fonts Trainable fonts
11.4 Interfaces
Type Lector63x Flex (V2D63xx-Mxxxxx)
Serial RS-232/422 Function: host 1 (data output of the read result)
Data transmission rate: 300 Bd ... 115.2 kBd
Serial RS-232 Function: AUX 1 (Service)
1)
Data transmission rate: 57.6 kBd
USB 2.0 Function: AUX 3 (Service)
1)
CAN Protocol: SICK CAN Sensor Network CSN (Master/Slave, Multiplexer/Server)
Function: host (data output of the read result)
Data transmission rate: 50 kBit/s ... 500 kBit/s
Bus length: maximum 30 m (depending on the data transmission rate)
Ethernet Protocols:
•
TCP/IP
•
EtherNet/IP™
Functions
•
host 2 (data output of the read result)
•
AUX 2 (Service)
1)
•
FTP (image transfer)
Data transmission rate: 10/100/1,000 MBit/s
MAC address (device-specific), see type label
PROFIBUS Function: host (RS-232, data output of the read result)
Type of fieldbus integration: optionally over external CDF600-21xx fieldbus module
3)
to bus
(RS-485)
Function blocks for various PLC manufacturers are available online at: www.sick.com/Lector63x
PROFINET (line topol‐
ogy)
Function: host (RS-232, data output of read result), PROFINET Single Port, PROFINET Dual Port
Type of fieldbus integration: PROFINET Single Port, PROFINET Dual Port optionally via external
CDF600-22xx fieldbus module
3)
to bus (Ethernet)
Function blocks for various PLC manufacturers are available online at: www.sick.com/Lector63x
Digital inputs Type: 2 physical, switching (“Sensor 1”, “Sensor 2”)
Optional 2 additional external logical inputs (software-controlled) via the CMC600
3)
parameter
cloning module in the CDB650-204
3)
or CDM420-0006
3)
connection module
V
in
4)
= max. 32 V, I
in
5)
= max. 5 mA
Opto-decoupled, reverse polarity protected, adjustable debounce time
Configurable inputs Encode input, external trigger
