11 Technical data
NOTE
The relevant online data sheet for your product, including technical data, dimensional
drawing, and connection diagrams can be downloaded, saved, and printed from the
Internet:
•
www.sick.com/Lector63x
Please note: This documentation may contain further technical data.
11.1
Features
Type Lector63x Flex (V2D63xx-Mxxxxx)
Focus Compact C-mount lens:
•
Fixed aperture
•
Manual sharpness adjustment (focus) on the lens
C-mount lens:
•
Manual sharpness and aperture setting on the lens
S-mount lens:
•
Fixed aperture
•
Short working distances can be achieved using spacer rings
•
Manual sharpness adjustment via focus screw on the top side of the device
Sensor For identifier, see see "Type code", page 14
Sensor resolution For identifier, see see "Type code", page 14
Integratable illumina‐
tion unit
Optional, e.g. with variants of the integrable VI55I ring illumination unit
6 LEDs, type-dependent combination of light colors:
•
Visible white light (T = 6,000 K ± 500 K)
•
Visible blue light (λ = 455 nm ± 20 nm)
•
Visible red light (λ = 620 nm ± 30 nm)
Feedback LED (spot in
field of view)
Optional, e.g. with variants of the integrable VI55I ring illumination unit
1 LED, switchable using the configuration software:
•
Visible green light (λ = 525 nm ± 15 nm), RG 1
•
Visible red light (λ = 630 nm ± 20 nm), RG 1
LED risk group (VI55I
ring illumination unit)
Variants of the integratable VI55I ring illumination unit (risk group RG 1)
•
Type “visible white light + feedback LED” (part number: 2078428, 2078430, 2078431)
•
Type “visible red light + feedback LED” (part number: 2098649, 2098650, 2084247)
•
Type “visible blue light - medium + feedback LED” (part number: 2083814)
•
Type “visible blue light - wide + feedback LED” (part number: 2083813)
Risk group RG 1 (low risk) according to IEC 62471-1: 2006-07/ EN 62471-1: 2008-09.
Radiance:
•
L
B
: < 10 x 10
3
W/(m
2
sr) within 100 s; at a distance of ≥ 200 mm
•
L
R
: < 7 x 10
5
W/(m
2
sr) within 10 s; at a distance of ≥ 200 mm
Variants of the integratable VI55I ring illumination unit (risk group RG 2)
•
Type “visible blue light - narrow + feedback LED” (part number: 2083812)
Risk group 2 (moderate risk) according to IEC 62471-1: 2006-07/EN 62471-1: 2008-09 due to
exposure to blue light.
Radiance:
•
L
B
1)
: < 10 x 10
3
W/(m
2
sr) within 50 s (RG 2); at a distance of ≥ 200 mm
•
L
R
2)
: < 7 x 10
5
W/(m
2
sr) within 10 s (RG 1); at a distance of ≥ 200 mm
Risk RG 1 (low risk) corresponding to L
B
< 10 x 10
3
W/(m
2
sr) within 100 s for distances > 1 m.
TECHNICAL DATA 11
8018071/16XD/2020-05-06 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector63x Flex C-mount and S-mount
67
Subject to change without notice
