Type Lector63x Flex (V2D63xx-Mxxxxx)
Digital outputs Type: 4 physical, switching (“Result1”, “Result2”, “Result3”, “Result4”)
When using the CDB420: 2 physical, switching (“Result1”, “Result2”)
Optional 2 additional external logical outputs (software-controlled) via optional CMC600 module in
the CDB650-204 or CDM420-0006 connection module
V
out
= V
S
8)
– 1.5 V, I
out
9)
≤ 100 mA
Short-circuit protected, not electrically isolated from the supply voltage
Configurable outputs Read confirmation, external illumination control, freely configurable output condition, “Device
Ready”
Reading pulse Digital inputs, free, serial interface, Ethernet, CAN, auto pulse, presentation mode
Optical indicators 5 status LEDs on the top side of the housing
5 bar graph LEDs on the top side of the housing
1 feedback LED for the integratable VI55I ring illumination unit (green or red, switchable display
behavior), as a light spot on the code
Acoustic indicator 1 beeper (buzzer), can be deactivated
Function for event notification with adjustable volume
Operating elements 2 buttons (select, start, stop functions)
Operator interfaces Web server
Configuration tools
(parameterization)
SOPAS ET configuration software, web server, CoLa commands (telegrams), fieldbus controller (PLC)
with additional support by SICK function blocks, function buttons
MicroSD memory card Micro SD memory card (flash card) max. 32 GB, optional
Data storage and
retrieval
image and data storage via microSD memory card and external FTP
Maximum encoder fre‐
quency
1 kHz
External illumination
control
Via digital output (max. 24 V trigger) or external illumination connection
1)
For example: Configuration, diagnosis, transponder access or display of the read result.
2)
Data interface only for temporary use (service).
3)
Optional accessories.
4)
Input voltage.
5)
Input current.
6)
For example using the SOPAS ET configuration software.
7)
Output voltage.
8)
Supply voltage.
9)
Output current.
11.5 Ambient data
Type Lector63x Flex (V2D63xx-Mxxxxx)
Electromagnetic com‐
patibility (EMC)
Electromagnetic immunity: EN 61000-6-2: 2005-08-01
Radiated emission: EN 61000-6-3: 2007-01-01 + EN 61000-6-3 / A1: 2011-03-01
Vibration resistance According to EN 60068-2-6: 2008-02
Shock resistance In accordance with EN 60068-2-27: 2009-05
Ambient operating
temperature
0 °C ... +50 °C
1)
Storage temperature –20 °C ... +70 °C
Permissible relative
humidity
0% ... 90%, non-condensing
Ambient light immu‐
nity
2,000 lx on code
1)
Observe the notes regarding adequate dissipation of heat loss: see "Installation requirements", page 26.
11 TECHNICAL DATA
70
O P E R A T I N G I N S T R U C T I O N S | Lector63x Flex C-mount and S-mount 8018071/16XD/2020-05-06 | SICK
Subject to change without notice
