Type Lector63x Flex (V2D63xx-Mxxxxx)
Laser alignment aid 2 LEDs, can be deactivated:
Visible red light (λ = 630 nm ... 680 nm)
Laser class Laser alignment aid:
Class 1 in accordance with EN/IEC 60825-1:2014 (identical to EN/IEC 60825-1:2007). Corre‐
sponds to 21 CFR 1040.10 except for tolerances according to Laser Notice 50 from June 24, 2007
and subsequent versions.
P < 0.39 mW
Scanning frequency 1.3 Mpx: ≤ 50 Hz
1.9 Mpx: ≤ 50 Hz
Code resolution ≥ 0.1 mm, depending on lens
Working range Depending on type, see "Field of view diagrams", page 33
Lens For identifier, see see "Type code", page 14
•
Can be replaced, see “LECTOR series image-based code reader” product information (part num‐
ber: 8016252, www.sick.com/8016252)
•
Complete device: lens mounted by SICK
•
Basic device: lens mounted by the user
1)
L
B
= Hazard from blue light.
2)
L
R
= Hazard to the retina of the eye due to heating.
11.2 Mechanics and electronics
Type Lector63x Flex (V2D63xx-Mxxxxx)
Electrical connection 1 male connector, M12, 17-pin, A-coded (serial, CAN, I/O, voltage supply)
1 female connector, M12, 8-pin, X-coded (Ethernet, 1 GBit/s)
1 female connector, M8, 4-pin, coded (USB)
1 female connector, M12, 4-pin, A-coded (control of external illumination unit)
Supply voltage V
S
Voltage source in accordance with ES1 and PS2 (EN 62368-1) or SELV and LPS (EN 60950-1).
DC 12 V ... 24 V ± 20%
Power consumption Operation: 10 W ± 20% typical
Current consumption Max. 1.5 A for a typical load of 100 mA on each of the 4 digital outputs
Housing material Die cast aluminum, plastic
Housing color Light blue (RAL 5012), black
Viewing window mater‐
ial
Glass or plastic (PMMA), 2 mm thick, with scratch-proof coating: see "Type code", page 14
Hinged cover (top side
of device)
Material: Plastic
Function: For temporary access to the memory card slot and the manual focus screw (S-mount)
Hinged
2)
, screws (SW2 hexagon key), captive
Enclosure rating For identifier, see see "Type code", page 14 (EN 60529, EN 60529/A2)
Protection class III
Electrical safety EN 62368-1
Weight 430 g, without lens and connecting cables
Dimensions (L x W x H) 08 mm x 63.1 mm x 45.8 mm
3)
1)
For digital outputs without load.
2)
When the cover is open, the device no longer conforms with the specified enclosure rating.
3)
see "Device view", page 17.
11 TECHNICAL DATA
68
O P E R A T I N G I N S T R U C T I O N S | Lector63x Flex C-mount and S-mount 8018071/16XD/2020-05-06 | SICK
Subject to change without notice
