Description of the motors
1.5 Selection and ordering data
1FT7 Synchronous Motors
20 Configuration Manual, (PFT7S) 01/2009, 6SN1197-0AD13-0BP2
1.5 Selection and ordering data
1FT7 Compact core type
Rated
speed
Shaft
height
Rated
power
Static
torque
Rated torque Rated
current
1FT7 Compact
synchronous motors
Natural cooling
Core type
Num-
ber of
pole
pairs
Rotor moment
of inertia (with-
out brake)
Weight
(without
brake)
n
rated
SH P
rated
at
ΔT=100 K
M
0
at
ΔT=100 K
M
rated
at
ΔT=100 K
I
rated
at
ΔT=100 K
Jm
rpm kW
(HP)
Nm
(lb
f
-ft)
Nm
(lb
f
-ft)
AOrder No. 10
-4
kgm
2
(10
-3
lb
f
-in-s
2
)
kg
(lb)
2000 100 5.03 (6.75)
7.96 (10.7)
30 (22.1)
50 (36.9)
24 (17.7)
38 (28)
10
15
1FT7102 - 1AC77 - 1771
1FT7105 - 1AC77 - 1771
5
5
91.4 (80.9)
178 (157)
26.1 (57.5)
44.2 (97.5)
3000 48 1.35 (1.81) 5.0 (3.7) 4.3 (3.2) 2.6 1FT7044 - 1AF77 - 1771 3 5.43 (4.81) 7.2 (15.9)
63 1.7 (2.28)
2.39 (3.20)
6.0 (4.4)
9.0 (6.6)
5.4 (4.0)
7.6 (5.6)
3.9
5.2
1FT7062 - 1AF77 - 1771
1FT7064 - 1AF77 - 1771
5
5
7.36 (6.51)
11.9 (10.5)
7.1 (15.7)
9.7 (21.4)
80 3.24 (4.34)
4.55 (6.10)
5.65 (7.58)
13 (9.6)
20 (14.8)
28 (20.7)
10.5 (7.7)
14.5 (10.7)
18 (13.3)
6.6
8.5
11
1FT7082 - 1AF77 - 1771
1FT7084 - 1AF77 - 1771
1FT7086 - 1AF77 - 1771
5
5
5
26.5 (23.4)
45.1 (39.9)
63.6 (56.2)
14 (30.9)
20.8 (45.9)
27.5 (60.6)
4500 80 4.82 (6.46)
3)
4.71 (6.32)
20 (14.8)
28 (20.7)
11.5 (8.5)
3)
10 (7.4)
10.1
3)
10
1FT7084 - 1AH77 - 1771
1FT7086 - 1AH77 - 1771
5
5
45.1 (39.9)
63.6 (56.2)
20.8 (45.9)
27.5 (60.6)
6000 36 0.88 (1.18) 2.0 (1.5) 1.4 (1.0) 2.1 1FT7034 - 1AK77 - 1771 3 0.85 (0.75) 3.8 (8.38)
63 2.13 (2.86)
1)
2.59 (3.47)
2)
6.0 (4.4)
9.0 (6.6)
3.7 (2.7)
1)
5.5 (4.1)
2)
5.9
1)
6.1
2)
1FT7062 - 1AK77 - 1771
1FT7064 - 1AK77 - 1771
5
5
7.36 (6.51)
11.9 (10.5)
7.1 (15.7)
9.7 (21.4)
Type of construction IM B5: Flange 0
Flange 1 (compatible with 1FT6)
0
1
Encoder systems for motors
without DRIVE-CLiQ interface:
Incremental encoder sin/cos 1 V
pp
2048 S/R
with C and D tracks
Absolute encoder EnDat 2 048 S/R
N
M
Encoder systems for motors
with
DRIVE-CLiQ interface:
22 bit incremental encoder with commutation position
Absolute encoder, 22 bit single-turn + 12 bit multi-turn
D
F
Shaft extension:
Plain shaft
Plain shaft
Shaft and flange accuracy:
Tolerance N
Tolerance N
Holding brake:
without
with
G
H
Vibration magnitude:
Grade A
Degree of protection:
IP65
1
