Siemens 1FT7 Configuration Manual

Description of the motors
1.6 Motor overview/Assignment of Motor Module
1FT7 Synchronous Motors
38 Configuration Manual, (PFT7S) 01/2009, 6SN1197-0AD13-0BP2
1.6 Motor overview/Assignment of Motor Module
Table 1- 3 Naturally cooled motors
SINAMICS Motor Module Motor type n
r
[rpm] M
r (100K)
[Nm]
I
r (100K)
[A] M
0 (100K)
[Nm]
I
0 (100K)
[A] n
max mech
[rpm]
I
r
[A] Order no.
1FT7034-❑AK7 6,000 1.4 2.1 2 2.7 10,000 3 6SL112❑-❑TE13-0AA❑
1FT7036-❑AK7 6,000 1.7 2.4 3 4 10,000 5 6SL112❑-❑TE15-0AA❑
1FT7042-❑AF7 3,000 2.7 2.1 3 2.1 9,000 3 6SL112❑-❑TE13-0AA❑
1FT7042-❑AK7 6,000 2 3 3 3.9 9,000 5 6SL112❑-❑TE15-0AA❑
1FT7044-❑AF7 3,000 4.3 2.6 5 2.8 9,000 3 6SL112❑-❑TE13-0AA❑
1FT7044-❑AK7 6,000 2 2.5 5 5.7 9,000 9 6SL112❑-❑TE21-0AA❑
1FT7046-❑AF7 3,000 5.6 3.5 7 4 9,000 5 6SL112❑-❑TE15-0AA❑
1FT7046-❑AH7 4,500 2.4 3.2 7 8.1 9,000 9 6SL112❑-❑TE21-0AA❑
1FT7062-❑AF7 3,000 5.4 3.9 6 3.9 9,000 5 6SL112❑-❑TE15-0AA❑
1FT7062-❑AK7 6,000 3.3 5.4 6 8.4 9,000 9 6SL112❑-❑TE21-0AA❑
1FT7064-❑AF7 3,000 7.6 5.2 9 5.7 9,000 9 6SL112❑-❑TE21-0AA❑
1FT7064-❑AK7 6,000 2.9 3.4 9 9 9,000 9 6SL112❑-❑TE21-0AA❑
1FT7066-❑AF7 3,000 9.3 7.2 12 8.4 9,000 9 6SL112❑-❑TE21-0AA❑
1FT7066-❑AH7 4,500 5 6.3 12 13.6 9,000 18 6SL112❑-❑TE21-8AA❑
1FT7068-❑AF7 3,000 10.9 6.7 15 8.3 9,000 9 6SL112❑-❑TE21-0AA❑
1FT7082-❑AC7 2,000 11.4 4.9 13 5 8,000 5 6SL112❑-❑TE15-0AA❑
1FT7082-❑AF7 3,000 10.3 6.6 13 7.6 8,000 9 6SL112❑-❑TE21-0AA❑
1FT7082-❑AH7 4,500 8 7.8 13 12.3 8,000 18 6SL112❑-❑TE21-8AA❑
1FT7084-❑AC7 2,000 16.9 8.4 20 9 8,000 9 6SL112❑-❑TE21-0AA❑
1FT7084-❑AF7 3,000 14.5 8.5 20 11 8,000 18 6SL112❑-❑TE21-8AA❑
1FT7084-❑AH7 4,500 9.5 7.8 20 15.6 8,000 18 6SL112❑-❑TE21-8AA❑
1FT7086-❑AC7 2,000 22.5 9.2 28 10.6 8,000 18 6SL112❑-❑TE21-8AA❑
1FT7086-❑AF7 3,000 18 11 28 15.5 8,000 18 6SL112❑-❑TE21-8AA❑
1FT7086-❑AH7 4,500 10 10 28 22.4 8,000 30 6SL112❑-❑TE23-0AA❑
1FT7102-❑AB7 1,500 26 8 30 9 6,000 9 6SL112❑-❑TE21-0AA❑
1FT7102-❑AC7 2,000 24 10 30 12.5 6,000 18 6SL112❑-❑TE21-8AA❑
1FT7102-❑AF7 3,000 20 12 30 18 6,000 18 6SL112❑-❑TE21-8AA❑
1FT7105-❑AB7 1,500 42 13 50 15 6,000 18 6SL112❑-❑TE21-8AA❑
1FT7105-❑AC7 2,000 38 15 50 18 6,000 18 6SL112❑-❑TE21-8AA❑
1FT7105-❑AF7 3,000 28 15 50 26 6,000 30 6SL112❑-❑TE23-0AA❑
1FT7108-❑AB7 1,500 61 16 70 18 6,000 18 6SL112❑-❑TE21-8AA❑
1FT7108-❑AC7 2,000 50 18 70 25 6,000 30 6SL112❑-❑TE23-0AA❑
1FT7108-❑AF7 3,000 20 12 70 36 6,000 45 6SL312❑-1TE24-5AA
 ,QWHUQDODLUFRROLQJ
SRVVLEOHXSWR$
 ([WHUQDODLUFRROLQJ
 0RWRU0RGXOHLQVLQJOHD[LVYHUVLRQ
 0RWRU0RGXOHLQWZRD[LVYHUVLRQ
0/)%IRU6,1$0,&60RWRU0RGXOH
1RWH
1RWH
7KHWDEOHVKRZVWKHSRZHUPRGXOHLQUDWHG
7KHWDEOHVKRZVWKHSRZHUPRGXOHLQUDWHG
RSHUDWLRQ$ODUJHUSRZHUPRGXOHPD\EHUHTXLUHG
RSHUDWLRQ$ODUJHUSRZHUPRGXOHPD\EHUHTXLUHG
IRUSHDNORDGRSHUDWLRQ
IRUSHDNORDGRSHUDWLRQ
7(

6/

$$
