1FT7 Synchronous Motors
Configuration Manual, (PFT7S) 01/2009, 6SN1197-0AD13-0BP2
231
Information on the application of motors
7
7.1 Transport / storage before use
During transport and if the motors are out of operation for a long period of time, the cooling
circuit must be completely drained to protect against frost damage and corrosion.
The motors should be stored indoors in dry conditions with low-dust and low vibration levels
(v
eff
< 0.2 mm/s). The motors should not be stored longer than two years at room
temperature (+5° C to +40° C) to retain the service life of the grease.
Observe the additional notes regarding transport and storage in the operating instructions.
7.2 Environmental conditions
Operating temperature range: -15° C to +40° C (without any restrictions).
All of the catalog data refer to an ambient temperature of 40° C, mounted so that the motors
are not thermally insulated and an installation altitude up to 1000 m above sea level.
Under conditions other than those specified above (ambient temperature > 40°C or
installation altitude > 1000 m above sea level), the permissible torque/power must be
determined using the factors from the following table.
Ambient temperatures and installation altitudes are rounded-off to 5° C or 500 m
respectively.
Table 7- 1 Factors to reduce the torque/power (de-rating)
Ambient temperature in ° C
Installation altitude above
sea level [m]
< 30 30 - 40 45 50 55
1000 1,07 1,00 0,96 0,92 0,87
1500 1,04 0,97 0,93 0,89 0,84
2000 1,00 0,94 0,90 0,86 0,82
2500 0,96 0,90 0,86 0,83 0,78
3000 0,92 0,86 0,82 0,79 0,75
3500 0,88 0,82 0,79 0,75 0,71
4000 0,82 0,77 0,74 0,71 0,67
