Siemens 1FT7 Configuration Manual

Description of the motors
1.6 Motor overview/Assignment of Motor Module
1FT7 Synchronous Motors
Configuration Manual, (PFT7S) 01/2009, 6SN1197-0AD13-0BP2
39
Table 1- 4 Liquid cooled motors
SINAMICS Motor Module Motor type n
N
[RPM]
M
N (100K)
[Nm]
I
N (100K)
[A] M
0 (100K)
[Nm]
I
0 (100K)
[A] n
max mech
[RPM]
I
N
[A] Order no.
1FT7062-5WF7 3,000 10 7.8 10 7.4 9,000 9 6SL312❑-❑TE21-8AA3
1FT7062-5WK7 6,000 9.2 12.7 10 12.5 9,000 18 6SL312❑-❑TE21-8AA3
1FT7064-5WF7 3,000 16 12.5 16 11.9 9,000 18 6SL312❑-❑TE21-8AA3
1FT7064-5WK7 6,000 14.2 20 16 20.2 9,000 30 6SL312❑-❑TE23-0AA3
1FT7066-5WF7 3,000 19.6 14.4 20 14.0 9,000 18 6SL312❑-❑TE21-8AA3
1FT7066-5WH7 4,500 19.4 20.8 20 19.7 9,000 30 6SL312❑-❑TE23-0AA3
1FT7068-5WF7 3,000 29.5 19.6 30 19.0 9,000 18 6SL312❑-❑TE21-8AA3
1FT7082-5WC7 2,000 21 11 21 10.7 8,000 18 6SL312❑-❑TE21-8AA3
1FT7082-5WF7 3,000 20.5 16 21 16 8,000 18 6SL312❑-❑TE21-8AA3
1FT7082-5WH7 4,500 19 23.9 21 24 8,000 30 6SL312❑-1TE23-0AA3
1FT7084-5WC7 2,000 35 17 35 16.5 8,000 18 6SL312❑-❑TE21-8AA3
1FT7084-5WF7 3,000 35 24.2 35 23 8,000 30 6SL312❑-1TE23-0AA3
1FT7084-5WH7 4,500 32 34.5 35 34.3 8,000 45 6SL312❑-1TE24-5AA3
1FT7086-5WC7 2,000 50 24 50 23 8,000 30 6SL312❑-1TE23-0AA3
1FT7086-5WF7 3,000 49 36 50 34 8,000 45 6SL312❑-1TE24-5AA3
1FT7086-5WH7 4,500 43 38 50 40.5 8,000 45 6SL312❑-1TE24-5AA3
1FT7102-5WB7 1,500 50 20.3 50 17.8 6,000 18 6SL312❑-❑TE21-8AA3
1FT7102-5WC7 2,000 49.5 29.3 50 25.5 6,000 30 6SL312❑-1TE23-0AA3
1FT7102-5WF7 3,000 45.5 38.8 50 40.0 6,000 45 6SL312❑-1TE24-5AA3
1FT7105-5WB7 1,500 90 29.5 90 28.2 6,000 30 6SL312❑-1TE23-0AA3
1FT7105-5WC7 2,000 90 40.8 90 39.0 6,000 45 6SL312❑-1TE24-5AA3
1FT7105-5WF7 3,000 79 49.5 90 53.2 6,000 60 6SL312❑-1TE26-0AA3
1FT7108-5WB7 1,500 125 40.3 125 39.0 6,000 45 6SL312❑-1TE24-5AA3
1FT7108-5WC7 2,000 125 47.5 125 45.3 6,000 45 6SL312❑-1TE24-5AA3
1FT7108-5WF7 3,000 109 60.0 125 65.0 6,000 85 6SL312❑-1TE28-5AA3
 ,QWHUQDODLUFRROLQJ
SRVVLEOHXSWR$
 ([WHUQDODLUFRROLQJ
 0RWRU0RGXOHLQVLQJOHD[LVYHUVLRQ
 0RWRU0RGXOHLQWZRD[LVYHUVLRQ
0/)%IRU6,1$0,&60RWRU0RGXOH
1RWH
1RWH
7KHWDEOHVKRZVWKHSRZHUPRGXOHLQUDWHG
7KHWDEOHVKRZVWKHSRZHUPRGXOHLQUDWHG
RSHUDWLRQ$ODUJHUSRZHUPRGXOHPD\EHUHTXLUHG
RSHUDWLRQ$ODUJHUSRZHUPRGXOHPD\EHUHTXLUHG
IRUSHDNORDGRSHUDWLRQ
IRUSHDNORDGRSHUDWLRQ
7(

6/

$$
