A5E00215731A AD
Siemens AG Operating Instructions 2.02 1PL618
21
Transport, assembly, and connection
3
3.1 Transport, storage, and maintenance
3.1.1 Transport, storage
Instructions relevant to safety
Please observe the following instructions on the transportation and storage of motors.
WARNING
Motors may only be attached to and hoisted by the main eyebolts that are located at the
end shields. Auxiliary eyebolts, e.g. on fan cowls and cooler attachments, are suitable only
for hoisting the respective parts.
To hoist the motor, in particular at attachments and built-on assemblies, use suitable cable-
guidance or spreading equipment.
Observe the lifting capacity of the hoisting gear.
(For weight, see rating plate and table "Weights of standard versions")
Table 3-1 Weights of standard versions (IM B3)
Type Weight
1PL6 184 Approx. 370 kg
1PL6 186 Approx. 440 kg
NOTICE
If the motor is not immediately commissioned, then it should be stored in a dry room which
is free from vibration and shock.
