Transport, assembly, and connection
3.3 Electrical connection
A5E00215731A AD
34 Siemens AG Operating Instructions 2.02 1PL618
[ID: 338.01]
3.3.5 Connecting the speed sensor
Connection
Connect the speed sensor to the terminal box by means of a plug-in connection ①. It is
located on top of the box housing.
Figure 3-6 Detailed view: Plug-in connection
Note
The plug-in connection may differ from the standard layout in the case of special orders.
In the version "without sensor", an armored conduit union is located here.
