Byte Meaning
Bit 0Bit 1Bit 2Bit 3Bit 4Bit 5Bit 6Bit 7
8 LAS slave
16B
LAS slave
17B
LAS slave
18B
LAS slave
19B
LAS slave
20B
LAS slave
21B
LAS slave
22B
LAS slave
23B
9 LAS slave
24B
LAS slave
25B
LAS slave
26B
LAS slave
27B
LAS slave
28B
LAS slave
29B
LAS slave
30B
LAS slave
31B
10 ID_CODE slave 0 I/O configuration slave 0
11 Ext ID1 slave 0 Ext ID2 slave 0
12 ID_CODE slave 1 I/O configuration slave 1
13 Ext ID1 slave 1 Ext ID2 slave 1
14 ID_CODE slave 2 I/O configuration slave 2
15 Ext ID1 slave 2 Ext ID2 slave 2
16 ID_CODE slave 3 I/O configuration slave 3
17 Ext ID1 slave 3 Ext ID2 slave 3
18 ID_CODE slave 4 I/O configuration slave 4
19 Ext ID1 slave 4 Ext ID2 slave 4
20 ID_CODE slave 5 I/O configuration slave 5
21 Ext ID1 slave 5 Ext ID2 slave 5
22 ID_CODE slave 6 I/O configuration slave 6
23 Ext ID1 slave 6 Ext ID2 slave 6
24 ID_CODE slave 7 I/O configuration slave 7
25 Ext ID1 slave 7 Ext ID2 slave 7
26 ID_CODE slave 8 I/O configuration slave 8
27 Ext ID1 slave 8 Ext ID2 slave 8
28 ID_CODE slave 9 I/O configuration slave 9
29 Ext ID1 slave 9 Ext ID2 slave 9
30 ID_CODE slave 10 I/O configuration slave 10
31 Ext ID1 slave 10 Ext ID2 slave 10
32 ID_CODE slave 11 I/O configuration slave 11
33 Ext ID1 slave 11 Ext ID2 slave 11
34 ID_CODE slave 12 I/O configuration slave 12
35 Ext ID1 slave 12 Ext ID2 slave 12
36 ID_CODE slave 13 I/O configuration slave 13
37 Ext ID1 slave 13 Ext ID2 slave 13
38 ID_CODE slave 14 I/O configuration slave 14
39 Ext ID1 slave 14 Ext ID2 slave 14
40 ID_CODE slave 15 I/O configuration slave 15
41 Ext ID1 slave 15 Ext ID2 slave 15
42 ID_CODE slave 16 I/O configuration slave 16
43 Ext ID1 slave 16 Ext ID2 slave 16
44 ID_CODE slave 17 I/O configuration slave 17
45 Ext ID1 slave 17 Ext ID2 slave 17
46 ID_CODE slave 18 I/O configuration slave 18
47 Ext ID1 slave 18 Ext ID2 slave 18
48 ID_CODE slave 19 I/O configuration slave 19
49 Ext ID1 slave 19 Ext ID2 slave 19
50 ID_CODE slave 20 I/O configuration slave 20
51 Ext ID1 slave 20 Ext ID2 slave 20
52 ID_CODE slave 21 I/O configuration slave 21
53 Ext ID1 slave 21 Ext ID2 slave 21
