Using the Command Interface
116
DP/AS-Interface Link 20E
Release 11/2002
C79000-G8976-C138–04
3.3.24 Write_AS-i_Slave_Extended_ID1
Meaning
With this call, the extended ID1 code of an AS-i slave with address “0” can be
written directly over the AS-i cable. The call is intended for diagnostic purposes
and is not required in the normal master mode.
The AS-i master passes on the extended ID1 code to the AS-i slave without any
plausibility check.
Structure of the Job Data in the Send Buffer
Byte Meaning
0 Command number: 3F
H
1 irrelevant Extended ID1 code
