Siemens DP/AS-Interface Link 20E User Manual

Technical Description, Installation Instructions, Operation
13
DP/AS-Interface Link 20E
Release 11/2002
C79000-G8976-C138–04
1.2 Application of the Module
DP Slave and AS-Interface Master
The DP/AS-i Link 20E module is both a PROFIBUS DP slave and an AS master at
the same time:
S The DP/AS-i Link 20E module connects the actuator-sensor interface with
PROFIBUS DP.
S Using the DP/AS-i Link 20E module, you can access the inputs and outputs of
the AS-i slaves from PROFIBUS DP. Depending on the slave type, you can
access binary values or analog values.
The following AS-i slaves can be used:
– Standard Slaves / AS–i Analog Slaves
– Slaves with the extended addressing mode
Branch
AS-i
power supply
Active module
(with slave ASIC)
Passive module
(without slave ASIC)
AS-i
cable
Actuator/sensor
with slave ASIC
Wider networking via PROFIBUS DP
DP/AS-Interface Link 20E
SF
APF
CER
AUP
CM
6GK7 1415 2AA0
1
2
3
4
5
6
7
8
0
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
X 2
3 4
DIA
ADR
BF
DP/AS-Interface
Link 20E
AS-i modules with the
extended addressing
mode
5A slave5B slave
Figure 1-1 Example of a System Configuration with the DP/AS-i Link 20E Module
