Using the Command Interface
104
DP/AS-Interface Link 20E
Release 11/2002
C79000-G8976-C138–04
154 reserved Parameters slave 1B
155 Parameters slave 2B Parameters slave 3B
156 Parameters slave 4B Parameters slave 5B
157 Parameters slave 6B Parameters slave 7B
158 Parameters slave 8B Parameters slave 9B
159 Parameters slave 10B Parameters slave 11B
160 Parameters slave 12B Parameters slave 13B
161 Parameters slave 14B Parameters slave 15B
162 Parameters slave 16B Parameters slave 17B
163 Parameters slave 18B Parameters slave 19B
164 Parameters slave 20B Parameters slave 21B
165 Parameters slave 22B Parameters slave 23B
166 Parameters slave 24B Parameters slave 25B
167 Parameters slave 26B Parameters slave 27B
168 Parameters slave 28B Parameters slave 29B
169 Parameters slave 30B Parameters slave 31B
170 Flag 1
171 Flag 2
172 reserved
... .....
218 reserved
Flag 1 Flag 2
Bit Number Meaning Bit Number Meaning
0 OFFLINE_READY 0 OFFLINE
1 APF 1 INTERNAL
2 NORMAL_MODE 2 EEPROM_OK
3 CONFIG_MODE 3 AUTO_ADDR_ENABLE
4 AUTO_ADDR_AVAIL 4 PERIPHERY_FAULT
5 AUTO_ADDR_ASSI_GN 5 reserved
6 LDS_0 6 reserved
7 CONFIG_OK 7 MPO startup
The meaning of the flags is the same as for the Get_LPS, Get_LAS, Get_LDS,
Get_Flags job.
