Siemens DP/AS-Interface Link 20E User Manual

Slave Diagnostics
131
DP/AS-Interface Link 20E
Release 11/2002
C79000-G8976-C138–04
Byte Value Purpose
17
60H
Fixed value
18
00H
Fixed value
19
40H
Fixed value
Byte Bit *) Value/meaning *)
20 0..7 1: Error in AS-i slave 0 to 7
21 0..7 1: Error in AS-i slave 8 to 15
22 0..7 1: Error in AS-i slave 16 to 23
23 0..7 1: Error in AS-i slave 24 to 31
24 0..7 1: Error in AS-i slave 0B.. 7B
25 0..7 1: Error in AS-i slave 8B..15B
26 0..7 1: Error in AS-i slave 16B..23B
27 0..7 1: Error in AS-i slave 24B..31B
*) Bit 0 belongs to slave 0, bit 1 belongs to slave 1 etc.
Note: Bytes 13 to 27 correspond to diagnostic data record 1 of SIMATIC S7.
-
