AS-Interface Protocol Implementation
Conformance Statement (PICS)
PICS for the DP/AS-Interface Link 20E
Table A-1
Vendor
SIEMENS AG
Product Name DP/AS-Interface Link 20E
Order Number 6GK1415-2AA01
Version 1
Master Profile M1e
Date 30.11.99
List of Master Functions Available
Table A-2
No.
Function or Call on the Host Interface
(symbolic representation)
M1e Comment / Function implemented by / see
Section
1 Image, Status = Read_IDI() X By access to the I/O data of the
DP/AS-Interface Link 20E by the DP
master.
2 Status = Write_ODI(Image) X By access to the I/O data of the
DP/AS-Interface Link 20E by the DP
master.
3 Status = Set_Permanent_Parameter(Addr,
Param)
X By the PROFIBUS parameter assignment
or by command (see Section 3.3)
4 Param, Status =
Get_Permanent_Parameter(Addr)
X see Section 3.3
5 Status, Param = Write_Parameter(Addr,
Param)
X see Section 3.3
6 Status, Param = Read_Parameter(Addr) X see Section 3.3
7 Status = Store_Actual_Parameters() X see Section 3.3
