69
Communication Port Connector
The communication port is connected to the USB port of the computer that has the FXS901-U2
programming tool. This is used to upload and/or download panel configuration if this method of
programming is used.
The computer must be disconnected from the panel if not in use.
LEDS, Buzzer and Dedicated Push Buttons
The LEDs operate as follows:
There are alarm events, and all alarm events
have been acknowledged.
There is no alarm event in system.
There are alarm events in system, but some of
them have not been acknowledged.
The system's power works normally. Both the
main power and battery are in normal status.
The system is not powered on. This LED can
be OFF only when the system is shut down.
The main power is in trouble and system is
powered via battery.
All outputs which can be silenced are silenced.
There are no silenced outputs in system.
Both silenced and unsilenced outputs exist.
There are trouble events, and all of them have
been acknowledged.
There is no trouble event in system.
There are trouble events in system, but some
of them have not been acknowledged.
There are supervisory events, and all of them
have been acknowledged.
There is no supervisory event in system.
There are supervisory events in system, but
some of them have not been acknowledged.
There are Ground Fault events in system.
