Siemens FC7xx User Manual

Operation
Switching off / Switching on
5
48 | 184
Building Technologies
A6V10211076_i_en_
--
Fire Safety
2015
-
12
-
15
5.4.2 Switching a detector off / on
If a deactivated '
Detector
' is the only '
Detector
' in a '
Zone
' or if all '
Detectors
' in a
'Zone' are deactivated, the 'Zone' is indicated as deactivated.
You will find information on temporarily
↑
switching off detectors in chapter
'Temporary switching-off [➙ 51]'.
↑ Switching off the 'Detector'
1. Select 'Main menu' > 'Topology'.
 The 'Topology' window is open.
2. Select 'Detection tree' and click <ok>.
 The elements of 'Detection tree' are displayed.
3. Select the element 'Area 1'.
 The elements of 'Area 1' are displayed.
4. Select 'Area 1' and press 'Lower level' <softkey 2>.
 All 'Sections' in 'Area 1' are displayed.
5. Select 'Section 1' and press 'Lower level' <softkey 2>.
 All 'Zones' in 'Section 1' are displayed.
6. Select 'Zone 1' and press 'Lower level' <softkey 2>.
 All detectors of 'Zone 1' are displayed.
7. Select 'Detect. 1' and press 'More Options' <softkey 3>.
 The 'Select option' window is open.
8. Select 'Execute commands'.
 The 'Select command' window is displayed.
9. WARNING! System parts that have been switched off make it impossible to
acquire and process alarms or faults! Select 'OFF'.
 The command is executed.
 The window with the command response is open.
 The detector is switched off.
Exemplary representation of the aforementioned operation sequence for
↑ switching off a detector:
Topology
Exit with <C>
Access level 2.1
↑ Detection tree
Hardware tree
↑ Control tree
(1)
(2)
(3)
Function
On/Off
Function
All
LED
test
κ Select 'Detection tree', continue with <ok>
