Siemens FC7xx User Manual

Operation
Execute commands
–
Basics
5
66 | 184
Building Technologies
A6V10211076_i_en_
--
Fire Safety
2015
-
12
-
15
002 Elements
Reception hall
Zone 1
Detect.
Detect.
1
2
Main entrance
Reception
Upper
level
Execute
Commands
κ Select 'Detect. 1', continue with 'Execute Commands' <softkey 3>
Select command
OFF
Activate alarm indicator
Deactivate alarm indicator
(1)
(3)
(4)
κ Select 'OFF' command continue with <ok>
 Command response
Execute command
OFF
Command executed
5.10.3 Executing commands – function-oriented
1. Select 'Main menu' > 'Functions'.
 The 'Functions' menu is open.
2. Select a menu item in the menu list or press the softkey in account.
If a command such as 'LED test' cannot be executed directly, the 'Select element
category' window is opened when a menu item or softkey is selected (see above,
in chapter 'Executing commands – General').
Functions
Exit with <C>
Access level 2.1
On / Off
Test
Activate / Deactivate
Information
(1)
(2)
(3)
(4)
Configuration
Maintenance
All functions
(5)
(6)
(7)
Function
On/Off
Function
All
LED
test
'Functions' menu
