5.12 Testing
5.12.1 Testing detectors
The 'Detector test' is a hardware function test for the devices and their assignment
to ↑ 'Detection tree'.
The 'Detector test' function can be carried out on the levels 'Zone', ↑ 'Section' or
'Area'.
The '
Detector test
' is available for all detector zone types.
Testing all automatic 'Detectors'
1. Select 'Main menu' > 'Functions'.
 The 'Functions' menu is open.
2. Select 'Test'.
 The 'Select element category' window is open.
3. Select the 'Element category' 'Area'.
 The 'Enter address' window is open.
4. Press <ok> without entering an address.
 The 'Select command' window is open.
5. Select 'Non-MCP zones det.test'.
 All automatic 'Detectors' are set to 'Detector test'.
 The 'DETECTOR TEST' LED on the ↑ Person Machine Interface is on.
6. Test the 'Detectors'.
Example of selecting commands for the 'Detector test' of all
automatic 'Detectors':
Select command
Installation test
Non-MCP zones det.test END
Installation test END
MCP zones det.test END
Non-MCP zones det.test
(2)
(3)
(4)
(5)
(6)
Ending the Detector test of all automatic 'Detectors'
Proceed as with Detector test but select the 'Non-MCP zones det.test END'
command.
