5.15 Polling reports
You can poll the following 'Reports' for the elements ↑ 'Reports', 'Station', 'Module',
or 'Line' in the 'Device' menu:
● 'Report SW version'/software version: Information on all firmware updates is
displayed in the FS720 system. There may be multiple software versions
available for one element.
● 'Report HW version'/hardware version: Information is displayed on the
hardware version, e.g., the hardware version of a detector.
Polling 'Reports' for the ↑ 'Station'
1. Select 'Main menu' > 'Functions' > 'Reports'.
The 'Select element category' window is open.
2. Select 'Station'.
3. Enter the address of the 'Station' and confirm with <ok>.
– or
4. Continue without entering an address and confirm with <ok>.
The 'Select command' window is open.
5. To display the software version, select 'Report SW version'.
– or
6. To display the hardware version, select 'Report HW version'.
The selected 'Reports' are displayed.
7. Optional: To print out the 'Reports', select 'Print report'.
Polling 'Reports' for individual 'Modules'
1. Select 'Main menu' > 'Functions' > 'Reports'.
The 'Select element category' window is open.
2. Select 'Module'.
You then have two options for selecting a 'Module':
● Selecting 'Module' with an address
● Selecting 'Module' from a list (without entering an address)
Selecting 'Module' with an address
1. Enter the address of the ↑ 'Station' and the 'Module' and confirm with <ok>.
The 'Select command' window is open.
2. To display the software version, select 'Report SW version'.
– or
3. To display the hardware version, select 'Report HW version'.
The selected 'Reports' are displayed.
4. Optional: To print out the 'Reports', select 'Print report'.
